Ra0.8um Surface Finish Butt Weld Fittings with Schedule 10 to XXS Wall Thickness for -50°C to 600°C Applications

Product Description:

Butt Weld Fittings are essential components used in piping systems to ensure secure and leak-proof connections between pipes. These fittings are designed to be welded directly to the pipe ends, providing a robust and permanent joint that can withstand high pressure and temperature conditions. Available in a wide range of sizes and specifications, Butt Weld Fittings are widely utilized in various industries including oil and gas, petrochemical, power generation, and water treatment.

The wall thickness of Butt Weld Fittings ranges from Schedule 10 to Schedule XXS, catering to different application requirements. This extensive range allows for flexibility in design and ensures compatibility with pipes of varying thicknesses, enhancing the overall strength and durability of the piping system. Whether you need fittings for light-duty or heavy-duty applications, the availability of multiple wall thickness schedules ensures that you can find the perfect match to suit your project needs.

Butt Weld Fittings are manufactured with strict adherence to quality standards, ensuring reliability and performance over time. The production year of these fittings is up to date, reflecting the latest advancements and improvements in manufacturing processes. This commitment to quality ensures that the fittings are free from defects and capable of performing efficiently under demanding conditions.

The temperature range for Butt Weld Fittings spans from -50°C to 600°C, making them suitable for use in a variety of environments, including extreme cold and high-temperature applications. This wide temperature tolerance makes these fittings ideal for industries where thermal expansion and contraction are common, as well as for processes involving heat transfer or cryogenic conditions.

Pressure rating is another critical attribute of Butt Weld Fittings, with options available from Class 150 to Class 2500. This broad spectrum of pressure classes allows the fittings to be used in low-pressure as well as high-pressure systems. The high-pressure ratings ensure that the fittings can handle intense operational pressures without compromising safety or integrity, making them suitable for critical applications in pipelines and process plants.

The surface finish of Butt Weld Fittings is maintained at a high quality with a surface roughness of Ra < 0.8um. This smooth surface finish is crucial for minimizing corrosion and ensuring ease of cleaning, which is particularly important in sanitary and food-grade applications. Additionally, a smooth surface finish contributes to better weldability, reducing the likelihood of defects during the welding process and ensuring a strong, clean joint.

Among the various types of Butt Weld Fittings, tees, elbows, and reducers are some of the most commonly used. The tee fitting allows for the branching of a pipeline, facilitating the division or combination of flow paths. Elbows are used to change the direction of the flow in the piping system, typically available in 45° and 90° angles to accommodate different layout requirements. Reducers are fittings that enable the connection of pipes with different diameters, ensuring a smooth transition in pipe size and maintaining the integrity of the flow.

In summary, Butt Weld Fittings offer a versatile and reliable solution for connecting pipes in industrial piping systems. With a wide range of wall thicknesses from Schedule 10 to Schedule XXS, temperature resistance from -50°C to 600°C, and pressure ratings from Class 150 to Class 2500, these fittings are designed to meet the demands of diverse applications. The high-quality surface finish of Ra < 0.8um further enhances their performance and longevity. Whether you require tees, elbows, or reducers, Butt Weld Fittings provide the strength, durability, and precision needed for efficient and safe piping installations.

Features:

• Product Name: Butt Weld Fittings
• High-quality reducer options available
• Surface finish: Ra<0.8um for smooth and precise fitting
• Pressure ratings: 3000lb and 6000lb suitable for various applications
• Temperature range: -50°C to 600°C to withstand extreme conditions
• Durable reducer design ensuring reliable performance
• Warranty: 3 Years for product assurance
• Certifications: ISO 9001, PED, AD2000, API, CE ensuring compliance and quality

Technical Parameters:

Applications:

TOBO Butt Weld Fittings, model number 5, are designed for a wide range of application occasions and scenarios where reliable and durable pipe connections are essential. Certified with ISO standards, these fittings ensure high quality and performance, making them suitable for use in industries such as oil and gas, petrochemical, power generation, water treatment, and construction. The product’s versatility is highlighted by its availability in various wall thicknesses ranging from Schedule 10 to Schedule XXS, accommodating different pressure and temperature requirements.

These fittings are ideal for scenarios where precise alignment and secure connections are critical. The TOBO Butt Weld Fittings come in multiple angle options, including 30, 45, 60, 90, 120, and 180 degrees, allowing for customized configurations in piping systems. Their surface treatment, featuring lathe finish and abrasive blasting, results in a smooth surface with Ra<0.8um, which not only enhances corrosion resistance but also facilitates easier welding and inspection processes. This superior surface quality is particularly beneficial in applications involving flange connections, where tight seals and minimal leakage are mandatory.

TOBO’s butt weld fittings are packaged securely in wooden cases to ensure safe transportation and delivery within 15 days after order confirmation. With a minimum order quantity of just 1 piece and a competitive price of 2.5 USD per fitting, these products are accessible for both large-scale projects and smaller maintenance needs. The fittings also come with a 3-year warranty, providing customers with confidence in their long-term durability and performance.

Payment terms are flexible with T/T accepted, making procurement straightforward for international buyers. The robust design and adherence to strict manufacturing standards make these TOBO fittings an excellent choice for connecting pipes in complex industrial systems, especially where flange connections and other fittings require secure, leak-proof joints. Whether used in new installations or repair works, TOBO Butt Weld Fittings offer dependable performance across a wide range of application occasions and scenarios.
